Aircraft Parameters
|
Product Type
|
Quadcopter
|
Product weight
|
3100g |
Flight radius
|
0-5000m |
Hovering accuracy
|
Vertical: 0.5m, Horizontal: 2.5m
|
Rotational angular velocity
|
Pitch axis: 300°/s,Heading axis: 150°/s
|
Upward speed |
5m/s |
Descent rate |
4m/s |
Flight Speed |
22m/s (ATTI mode, no load, no wind environment near sea level) | 17m/s (GPS mode, no load, no wind environment near sea level) |
Wheelbase |
650mm |
Adaptation to working environment temperature |
-35°C to 40°C (plus insulation) |
Pitch angle |
35° |
Withstand wind speed |
Level 5 |
Hover time (two batteries) |
No load: not less than 50 minutes |
Display devices |
Display devices |
7" Tablet |
Flight Control Software |
1, the software is simple to operate, with intelligent navigation functions, the use of personnel can operate according to the steps prompted |
2, can automatically plan the route, automatic aerial photography and return |
3、One key take-off and landing function |
4、 Real-time adjustment of the heading is possible |
5、System configuration and data saving, set up once for the same site |
Software Features |
1、Software running platform Windows 7 and above; |
2、Full automatic high-precision 3D modeling, more than 99.5% accuracy of disk material; |
3、Ability to remove the invalid data outside the yard area, able to calculate the volume and weight; |
4、 the function of unified inventory and partition calculation of volume, data editing function can be realized. |
5、can display all the material field model drawings under one interface, and support 3D dynamic browsing. |
6、Colorful display of model color: different material fields can be displayed in different colors, easy to distinguish |
7、invisible foundation surface processing function: for the foundation surface is deeply buried under the material pile, the function can be used to automatically deal with the situation, eliminate the error. |
8、the software can be integrated with other laser inventory equipment to facilitate future upgrades to expand the automatic generation of standard format reports. |
